當拍門漏水的時候我們怎么辦?根據小編的技術要求來總結：首先要檢查門瓣蓋是否太輕，壓力不夠，造成泄漏現象。解決的辦法是在活門蓋上加一些重物，增加壓力，解決玻璃鋼活門生產工藝和材料泄漏故障：采用現代玻璃鋼先進工藝配方，在特殊模具中熟化，然后經過后處理，加工。其主要原料有不飽和聚酯樹脂、玻璃纖維布、玻璃纖維短切紗、玻璃纖維紗等。本產品可分為圓拍門和方拍門。按連接形式可分為法蘭連接、混凝土澆注、手糊對接、套筒;按結構形式可分為空心浮板、平板、泵。

　　When the flap door leaks, what should we do? According to the technical requirements of Xiaobian, we should first check whether the flap cover is too light and the pressure is not enough to cause leakage. The solution is to add some weight on the valve cover, increase the pressure, and solve the problem of FRP valve production process and material leakage: adopt modern FRP advanced process formula, mature in special mold, and then after post-treatment, processing. Its main raw materials are unsaturated polyester resin, glass fiber cloth, glass fiber chopped yarn, glass fiber yarn, etc. This product can be divided into round door and square door. According to the connection form, it can be divided into flange connection, concrete pouring, hand paste butt joint and sleeve; according to the structure form, it can be divided into hollow floating plate, flat plate and pump.

多年來，鋼球拍門在出口處受到逆流灌溉的嚴重影響，球拍門經常損壞和脫落，從而影響出水泵的水質和密封性能。大量的零件已多次更換和維修，但由于強度、磨損、銹蝕等諸多因素，無法進行工藝修正。經常連續穩定地運行，這對順利完成工廠的生產任務指標有很大的影響。同時，對受損皮瓣的日常維護和搶救也消耗大量的人力、物力和財力。過去，泵站的球拍門在逆流倒灌的沖擊下容易損壞。由于鑄鐵強度和脆性差，難以承受多次重載沖擊。從長遠來看，泵站的球拍門會被打破和破碎。為了降低出口水位，在維護和更換過程中，必須增加泵的開口數量。機組人員跳入出水口，搶救破碎的扇門碎片，避免碎片被沖入出水泵葉片損壞。打撈過程費時費力，水下作業會有一些不安全因素。泵站門訂單或詢價應注意以下內容：產品名稱、數量和口徑;產品材料;產品連接法蘭穿孔尺寸按等級大小排列。

　　For many years, the steel racket gate has been seriously affected by counter current irrigation at the outlet. The racket gate is often damaged and falls off, which affects the water quality and sealing performance of the outlet pump. A large number of parts have been replaced and repaired for many times, but due to strength, wear, corrosion and many other factors, process modification can not be carried out. The continuous and stable operation of the plant has a great influence on the successful completion of the production tasks of the plant. At the same time, the daily maintenance and rescue of the damaged flap also consumes a lot of manpower, material resources and financial resources. In the past, the racket gate of pumping station was easy to be damaged under the impact of reverse flow. Due to the poor strength and brittleness of cast iron, it is difficult to bear repeated heavy load impact. In the long run, the racket door of the pumping station will be broken and broken. In order to reduce the outlet water level, it is necessary to increase the number of pump openings in the process of maintenance and replacement. The crew jumped into the water outlet to rescue the broken pieces of the door to prevent the pieces from being washed into the water outlet pump blade. The fishing process is time-consuming and laborious, and there are some unsafe factors in underwater operation. It should be arranged according to the following contents: the number of flange and the size of the product.

如果要確保拍門不漏水，需要清理框架梁上的水泥、碎片、油漬，涂防水密封膠(或橡膠墊)，在框架梁上的錨固螺栓上安裝復合擋板門，反復對稱均勻地擰緊螺帽，邊擰邊檢查復合擋板蓋和復合擋板門。閥座密封面環境，擰緊所有螺栓，閥瓣門蓋應能自由開啟和關閉，無阻塞跡象，密封面應無間隙。

　　To ensure that the flap door is watertight, it is necessary to clean up the cement, debris and oil stains on the frame beam, apply waterproof sealant (or rubber pad), install the composite baffle door on the anchor bolt on the frame beam, tighten the nuts symmetrically and evenly repeatedly, and check the composite baffle cover and the composite baffle door while screwing. The sealing surface of the valve seat shall be in good condition. All bolts shall be tightened. The valve disc and cover shall be able to open and close freely without obstruction. The sealing surface shall have no clearance.

　　還需要做到以下幾點：We also need to do the following:

　　1、錨栓、螺母和墊圈應采用鍍鋅或不銹鋼件，安裝后應刷兩次防腐涂層。每個地腳螺栓都應該配備一個螺帽、一個平墊和一個彈簧墊。

　　1. Anchor bolts, nuts and washers shall be galvanized or stainless steel parts, and shall be applied with anti-corrosion coating twice after installation. Each anchor bolt shall be equipped with a nut, a flat pad and a spring pad.

　2、錨固螺栓的分布應以豎向為基礎，延長基礎平面的長度。

　　2. The distribution of anchor bolts should be based on the vertical, and the length of foundation plane should be extended.

　　3、當拍門安裝時，軸的度數應該是固定的。3. When the flap door is installed, the degree of the shaft should be fixed.

　　4、拍門也可以安裝和固定種植螺栓和膨脹螺栓。在扁平混凝土框架表面上，根據閘門的法蘭螺栓孔的位置繪制鉆孔位置，并根據種植螺栓和膨脹螺栓的規格用直徑為2mm的鉆頭鉆孔。螺栓固化后，可安裝復合擋板門。

　　4. The flap door can also be installed and fixed with planting bolts and expansion bolts. On the surface of the flat concrete frame, the drilling position is drawn according to the position of the flange bolt hole of the gate, and the drill with a diameter of 2mm is used according to the specifications of the planting bolt and the expansion bolt. After the bolt is cured, the composite baffle door can be installed.

5、安裝混凝土澆注球拍門時，用支架固定鋼球拍門，并使中心線稍微向上邊緣1-2度，球拍門鉸鏈軸應放置到一定程度。澆注時，水泥和礫石不能進入球拍門蓋和鉸鏈軸。

5. When installing the concrete pouring racket door, fix the steel racket door with the bracket, and make the center line slightly upward 1-2 degrees. The hinge axis of the racket door should be placed to a certain extent. When pouring, cement and gravel shall not enter the racket door cover and hinge shaft.
