機閘一體鋼閘的特點 Characteristics of machine gate integrated steel gate

Views : Update time : 2020-12-30 18:42:35

機閘一體鋼閘門廣泛應用于水利水電、市政建設、給水排水、水產養殖、農用水利建設等工程。 是榮程水利生產的20多種閘門中的一種鋼制閘門,該設備有啟閉機和閘門一塊組合,該設備結構合理,便于安裝,操作簡便靈活,便于管理。 防腐能力強,可在PH=6-8的流體酸堿中使用。 止水效果好;正常滲水量L≤0.07L/m.s。

  Machine gate integrated steel gate is widely used in water conservancy and hydropower, municipal construction, water supply and drainage, aquaculture, agricultural water conservancy construction and other projects. It is a kind of steel gate in more than 20 kinds of gates produced by Rongcheng water conservancy Co., Ltd. The equipment has a combination of hoist and gate. The structure of the equipment is reasonable, easy to install, easy to operate and flexible, and easy to manage. It has strong anti-corrosion ability and can be used in pH = 6-8. The results show that the water sealing effect is good, and the normal seepage volume L ≤ 0.07l/m.s.

  機閘一體閘門具有:The machine gate integrated gate has:

1、機閘一體式閘門正常使用水頭1-6.5米,還可承受一定的反向水頭,為滿足用戶要求,可制造高水頭閘門。

  1. The normal working head of the machine gate integrated gate is 1-6.5m, and it can also bear certain reverse head. In order to meet the requirements of users, the high head gate can be manufactured.

  2、閘門安裝用整體安裝,二期澆注,將閘板與閘框的封水間隙調到0.3mm以下,方可進行二期澆注。

  2. The gate shall be installed as a whole and poured in the second stage. The second stage pouring can be carried out only when the water sealing gap between the gate and the gate frame is adjusted to less than 0.3mm.

 3、機閘一體閘門在澆注混凝土時,流進閘板、閘框、斜鐵、擋板間隙中的灰漿必須清除,防止灰漿凝固后影響閘門啟閉。

  3. When pouring concrete for the machine gate integrated gate, the mortar flowing into the gap between the gate, gate frame, inclined iron and baffle must be removed to prevent the influence of the opening and closing of the gate after the mortar solidifies.

  4、閘門上下框設有固定塊,可防止閘板在運輸吊裝等過程中滑出,安裝凝固后(使用前)應先卸掉上閘框的固定塊和下框緊回螺栓,方可啟動。

  4. The upper and lower frames of the gate are equipped with fixing blocks to prevent the gate from sliding out during transportation and hoisting. After installation and solidification (before use), the fixing blocks of the upper gate frame and the tightening bolts of the lower frame should be removed before starting.

5、機閘一體式鑄鐵閘門啟閉時,應注意閘板的上下板限位置,以免損壞閘門或啟閉機。

  5. When the machine gate integrated cast iron gate is opened and closed, attention should be paid to the upper and lower limit position of the gate to avoid damaging the gate or the hoist.

  機閘一體鋼閘門按閘門的結構形式分為:According to the structural form of the gate, the machine gate integrated steel gate is divided into:

PZ型平面平板門和PGZ型平面拱形門,又可分為整體式和組裝式兩種,規格齊全從0.2x0.2—6.5x6.5m(6.5x6.5m米或者水頭高為6.5m米)并生產矩形鑄鐵閘門;出水口>=3米時,為雙吊點閘門。機閘一體式鑄鐵閘門主要適用與正向受壓止水,根據用戶需要可制造反向止水閘門。 在結構上采用機加工硬止水,較大閘門底封水亦可采用橡膠封水。 根據用戶要求,可采用鑲銅或鑲不銹鋼止水,該設備可以根據客戶需要做成鑄鐵的,鋼的和不銹鋼的,滿足不同地方不同客戶需要,業務咨詢13582492022孫經理,微信同號。

  PZ type plane flat gate and PGZ type plane arch gate can be divided into integral type and assembled type, with complete specifications, from 0.2x0.2 to 6.5x6.5m (6.5x6.5m or head height of 6.5m) and the production of rectangular cast iron gate; when the outlet is > 3M, it is double lifting point gate. The machine gate integrated cast iron gate is mainly suitable for forward pressure sealing, and the reverse sealing gate can be manufactured according to the needs of users. In the structure, machining hard water seal is used, and rubber water seal is also used for the bottom sealing of larger gate. According to the user's requirements, copper inlaid or stainless steel inlaid water stop can be used. The equipment can be made into cast iron, steel and stainless steel according to the customer's needs, meeting the needs of different customers in different places. Business consulting 13582492022, manager Sun, wechat is the same number.
